Product Overview
This thermal break aluminum single door features a square top design built from 6063-T5 extruded aluminum with polyamide thermal break strips — lightweight, corrosion-resistant, and energy efficient. The thermal break reduces heat transfer significantly, making it ideal for Texas's extreme climate. Available in 0-Lite, 3-Lite, 4-Lite, 6-Lite, and Custom Size.
Product Details
| Door Type | Thermal Break Aluminum Single Door |
| Top Style | Square Top |
| Material | 6063-T5 Extruded Aluminum + Polyamide Thermal Break, Powder Coated |
| Thermal Break | PA66 GF25 Polyamide strip – significantly reduces heat transfer |
| Glass | 1" dual pane Argon-filled tempered glass |
| Glass Options | 0-Lite | 3-Lite | 4-Lite | 6-Lite | Custom Size |
| Hardware | Pre-bored for standard locking systems |
| Seal System | EPDM Rubber Seal |
| Standard Sizes | 37" x 80" | 37" x 96" | Custom sizes available |
Material and Construction
- 6063-T5 Extruded Aluminum: Lightweight, strong, and naturally corrosion-resistant — never rusts.
- Polyamide Thermal Break (PA66 GF25): Bonded inside the frame cavity — significantly reduces heat transfer.
- Powder-Coated Finish: Durable coating available in custom colors — resists chips, fading, and UV.
- Energy-Efficient Glass: 1" thick dual pane tempered glass with Argon gas fill.
- EPDM Rubber Seal: Weather-tight — blocks drafts, moisture, and dust.
About Thermal Break Doors
- Aluminum thermal break doors use a polyamide layer bonded inside the frame to stop heat conducting through.
- Lighter than steel, never corrodes, and available in custom colors.
- Ideal for Texas climate — reduces energy bills and condensation year-round.
Glass Options
- Single-Pane Tempered Glass – Clear, Tinted, Frosted, or Decorative
- Standard Double Glazing – Improved insulation
- Low-E Double Glazing – Energy-saving
- Laminated Glass – Maximum strength and security
Key Features
- 6063-T5 aluminum — lightweight and corrosion-resistant
- Polyamide thermal break for superior energy efficiency
- Square top — 0/3/4/6-Lite and Custom Size options
- Energy-efficient 1" dual pane Argon-filled glass
- EPDM rubber weather seal
- Custom sizes and colors available
